Bottom Sealing Bag Making Machine

Name: China Cheap Bottom Sealing Bag Making Machine Manufacturers Suppliers Factory - Good Price - Shengxiang Packaging Machinery
Brand: Shengxiang
SKU: 223760620

SX-DF1200 Bottom Sealing Bag Making Machine
Provided by Shengxiang
Can support multi layer material rack
China brand step motor
Manual loading system (Optional auto loading for single rack only)
Without automatic EPC system
Photo electric tracking eye
With work table.

Send Inquiry

Description

Technical Parameters

Product Description

This bottom sealing bag making machine using HDPE, LDPE, PE 2 layers Co-extrusion film to produce printed plastic vest bag, T shirt bag and flat bag;

The main motor adopts a frequency conversion motor, which saves power and allows you to adjust the speed more freely. The color mark tracker with good performance makes the sealing and cutting length more accurate and the error smaller. Using advanced computer, the length adjustment is convenient and accurate.

Features:

1. The frequency conversion and speed regulation of the main engine adopts well-known frequency converter (can be specified)

2. The whole machine is controlled by microcomputer, and the stepping motor is used for stripping (servo motor control system is optional)

3. Constant temperature heat sealing.

Machine Basic Parameters

Model	SX-DF1200	SX-DF1300	SX-DF1500	SX-DF1700
Max Bag Making Width	1100 mm	1200 mm	1400 mm	1600 mm
Max Bag Making Length	2500 mm	2500 mm	3000 mm	3000 mm
Bag Making Thickness	0.05-0.4 mm	0.05-0.4 mm	0.05-0.4 mm	0.05-0.4 mm
Bag Making Speed	5-100 pcs/min	5-100 pcs/min	5-100 pcs/min	5-100 pcs/min
Main Motor	2.2 kw	2.2 kw	2.2 kw	2.2 kw
Total Power	6.8 kw	7.2 kw	7.8 kw	8.2 kw
Weight	1500 kg	1700 kg	2000 kg	2200 kg
Overall Size (L x W x H)	380018001700 mm	380019001700 mm	540023001400 mm	540023001400 mm

FAQ

How to place an order?

Product Consultation-> Business negotiation-> Provide plans-> follow-up matters-> arrange deposit-> production-> before delivery (if you need to check the goods, it can be notified us)-> Inspection-> payment settlement- > Packing and Delivery-> Preparations before the factory-> On-site Installation-> Service Feedback-> More cooperation and referral. Detailed content can be seen -trade processes.

Are you a factory?

We are a factory, located in Ruian, Zhejiang, China.

How much space does this machine take?

Different devices have different venue requirements. For details, please consult our sales service consultant.

How many personnel do I need to operate this machine?

SX-DF1200 bottom sealing bag making machine need one labor for machine operator.

What should I prepare before the equipment arrives at the factory?

We have a list and a spare parts procurement list to meet different needs of transaction customers.
